 罐采用優質SUS304不銹鋼制成。既清潔衛生，又耐腐蝕，并經過精密拋光，污垢不宜積存。制冷板的制冷效率高，兩塊制冷板分別用兩套制冷壓縮機組控制，可以單獨或同時工作，保證牛奶冷卻快速均勻而無結冰現象。因保溫層采用導熱系數低的硬質泡沫材料充填，故質量輕，保溫性能優。
直冷式儲奶罐采用全自動控制， 電控箱可安裝于奶罐側面或近端，便于自動控制。奶罐設備與電器控制箱相結合，能對制冷系統作自動溫度控制。壓縮機有高壓壓力故障保護及電機過載保護(高壓保護值為 2.0MPa 、低壓停機值為 0.2MPa )，如遇上述故障，電路會自動斷開，報警，壓縮機將停止工作，此時必須檢查且排除故障，才可按復位按紐，繼續工作。奶罐需要預冷時，可手動開機。攪拌電機與壓縮機同步工作，當壓縮機停止工作時，如需要，可將攪拌開關打至自動檔，此時，攪拌器將進入可調節的間歇轉動。
當長時間存放牛奶，如缸內奶溫高于 6 ℃(可進行調節)時，壓縮機將自行啟動，進行制冷，直至罐內奶溫降到低于 4 ℃(可進行調節)時自動停機，從而達到保冷目的。
The tank is made of high quality SUS304 stainless steel. Both clean and sanitary, but also corrosion-resistant, and after precision polishing, dirt should not be accumulated. Refrigeration plate cooling efficiency is high, two cooling plates were used two sets of refrigeration compressor control, can work alone or at the same time to ensure that the milk cooling fast and uniform without freezing phenomenon. Because the insulation layer with low thermal conductivity of rigid foam filling, so the light weight, excellent insulation performance.
Direct-cooled milk tank with automatic control, electronic control box can be installed in the side of the milk tank or near the end, easy to automatic control. Milk tank equipment and electrical control box combined to the refrigeration system for automatic temperature control. Compressor has high pressure fault protection and motor overload protection (high voltage protection value of 2.0MPa, low pressure shutdown value of 0.2MPa), in case of the above failure, the circuit will automatically disconnect, alarm, the compressor will stop working, this time must check And troubleshooting, can press the reset button to continue to work. When the milk tank needs to be pre-cooled, it can be manually turned on. The stirring motor is operated synchronously with the compressor. When the compressor is stopped, if necessary, the stirring switch can be hit to the automatic gear. At this time, the stirrer will enter the adjustable intermittent rotation.
When the milk is stored for a long time, if the cylinder temperature is higher than 6 ° C (adjustable), the compressor will start and cool until the tank temperature drops below 4 ° C (can be adjusted) , So as to achieve the purpose of cold.
|
